Features
- Adjustable Gap Electrodes: Higher usage rate compared to disposable electrodes (electrode tube, high-voltage capacitor rated for 600,000 cycles).
- Pet-Specific High-Power Electromagnetic Disc: Rated for 300,000 cycles, ensuring long-lasting performance.
- Mitsubishi Japan PLC Programmable Controller: Offers stable performance, easy maintenance, and low failure rates.
- Liquid Nitrogen Heat Treatment: 1 cm thick steel plate layered with liquid nitrogen for heat treatment, ensuring minimal focal shift.
- Ultrasound Probe with Mechanical Arm: Capable of both rotational and orbital motion—patented technology.
Shock Wave Generator
- Shock Wave Source: Electromagnetic shock wave generator
- High Voltage Discharge Range: 9-18.5 kV
- Total Energy of High Voltage Capacitor: 50 ~ 150 J
- Compression Sound Pressure Peak: 20 MPa ~ 50 MPa
- Expansion Sound Pressure Peak: < 10 MPa
- Shock Wave Pressure Pulse Width: < 1 μs
- Shock Wave Pressure Pulse Rise Time: < 0.5 μs
- Electromagnetic Shock Wave Disc Lifespan: Approximately 300,000 cycles
- Focal Spot: 0.2 cm
